The analog circuit training system is designed for experiment teaching of basic analog circuits design. The design principal of the system is to inspirit the students' self-inspiration and their interest in analog circuit design.

Training Project with USB Cable

The DG4000 Series waveform generators are utilized in a wide range of applications because of the many functions combined into one instrument. With capabilities including Function Generation, Arbitrary Waveform Generation, Pulse Generation, Harmonic Generation, Analog/Digital Modulation source, and Counter the DG4000 series can handle a broad array of signal emulation applications from near DC up to 60 or even 200 MHz depending on model and function. The DG4000 utilizes Direct Digital Synthesizer (DDS) technology which delivers stable, precise, low distortion signals. The sleek, upright design features a high resolution 7" display screen, while the user-friendly interface design and panel layout improves efficiency.

The DM3000 Series DMMs give reliable, cost effective, full DMM capabilities measuring DCV, ACV, DCI, ACI, Resistance (2 & 4 Wire), Capacitance, Diode Test, Frequency, and Temperature. These DMMs are designed for simple and efficient bench top use, but include software options for datalogging and remote programming from almost any interface. The DM3000 can fit any DMM application with speed, accuracy, reliability, and efficiency well beyond its price.

EZ Digital DS-1250 250MHz Digital Oscilloscope are featured with DC to 250MHz, maximum 100MS/s realtime sampling per channel (Maximum of one channel: 200MS/s), equivalent sampling rate of 25GS/s. Its 16bit high speed microprocessor adoption enables to acquire maximum 100,0000 points per second and prompt update the picture on the screen. EZ Digital DS-1250 250MHz Digital Oscilloscope basic memory capacity is 32KBytes and captured waveforms can be zoomed in and analyzed in detail. Also its built-in 10ns peak detection circuit enables to capture high frequency noise at a low speed time/div and magnify and analyze it using the zoom-in function. It can save up to 10 waveforms and provides diversified analysis function like FFT which is available at high-end products.

The Rigol DS2102A is a very high quality two channel digital storage oscilloscope. It features a real-time sample rate of up to 2 GSa/s and a bandwidth of 100 MHz. The Rigol oscilloscopes are equipped with well designed and easy to use controls offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages. This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The DS2072A has a refresh rate of up to 50.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes. The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.

Professional FTTH tool kit contains the most essential tools for fiber optic fusion splice, Mechanical Splicing and patch cord termination procedure. Ideal for fiber optic installation and maintenance works.

UNO-R3-2012-1Uno R3 kit Ardio 90 part Starter Kit
