Description
Features
- Up to 100 MHz bandwidth
- 4 GSa/s sample rate (analog); 1 GSa/sec (digital)
- 2 Analog channels
- 16 Digital Logic Channels available
- 140 MPts memory (analog), 28 Mpts memory (digital)
- 110,000 Waveforms per second (analog); 85,000 Wfms/sec (digital)
- Original UltraVision technology
- Hardware allows for real-time, continuous waveform recording and waveform analysis
Specification
Model
MSO4012
Analog Channels
2
Digital Logic Channels
16
Frequency
100 MHz
Memory Depth
140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate
110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
